Датчик давления, 7000 фунтов/кв. дюйм Caterpillar 5923506

The Pressure Sensor for the suspension cylinder is designed to measure hydraulic pressure levels within the suspension system of equipment. It provides real-time data on the pressure conditions, allowing for accurate monitoring and adjustment of the suspension system. The pressure sensor continuously monitors the hydraulic pressure within the suspension cylinder. This pressure is a main parameter in determining the load on the suspension and the compression or extension of the suspension components.Attributes:• Facilitates accurate adjustment and control.• Withstand vibrations and temperature fluctuations.• Sensed pressure range is 48263.3 kilopascal(7000 Pound-force per square inch) gauge.• Proof pressure 96526.6 kilopascal(14000 Pound-force per square inch).• Burst pressure 144789.9(21000 Pound-force per square inch).• Supply voltage 8 - 32 Volts direct current. • Supply current 35 mA maximum.• Output type is variable frequency.• Operating temperature -40°C to 110°C.• Storage temperature -55°C to 135°C.Applications: The Pressure Sensor is used to monitor hydraulic pressure, providing data for the effective control and adjustment of the suspension system, contributing to optimal performance and operator comfort.
